New engine gasoline L4 1.6L G4LE GDI EURO-5-6 assy-sub complete set for Hybrid Hyundai Kia vehicles 2016-25 year.

Kappa II GDi HEV

Announced in 2016 and intended for use in Hybrid applications, main improvements are utilizing Atkinson cycle, higher compression ratio, cooler EGR system and higher-pressure fuel system.

The 1,580 cc (1.6 L) four-cylinder with a 72 mm (2.8 in) bore, 97 mm (3.8 in) stroke and a 13.0:1 compression ratio. The engine makes 105 PS (104 hp; 77 kW) at 5,700 rpm and 15 kg⋅m (147 N⋅m; 108 lbf⋅ft) of torque at 4,000 rpm.

The Hybrid version combines a 1.56 KWh battery with an electric motor making 44 PS (43 hp; 32 kW) between 1,800 and 2,500 rpm with 17.3 kg⋅m (170 N⋅m; 125 lbf⋅ft) of torque between 0 and 1,800 rpm.

The Plug-in Hybrid version combines a 8.9 KWh battery with an electric motor making 60.5 PS (60 hp; 44 kW) between 1,800 and 2,500 rpm with 17.3 kg⋅m (170 N⋅m; 125 lbf⋅ft) of torque between 0 and 1,800 rpm.

Both the Hybrid and Plug-in Hybrid versions total combined system power is 141 PS (139 hp; 104 kW) at 5,700 rpm with 27 kg⋅m

Part Name: 20-201A-G4LE 16-25Y

Displacement cc: 1580 (1.6 liters), Power 140Hp (103kWt), water-cooled, timing belt

Fuel: Gasoline (DOHC, GDI)

Number of cylinders: Cylinder head type L4, 16VL, Dual CVVT

Model Numbers: 1B04103U00 1B07103U00

Vehicle compatible: HYUNDAI KONA HYBRID 2019-20 YEAR

                                    HYUNDAI IONIQ HYBRID 2016-22 YEAR

                                    KIA NIRO HYBRID  2016-25 YEAR

MANUFACTURER: MOBIS

ORIGIN: MADE IN KOREA

ATTENTION: For verification, compatible of specification after place order need indicate VIN-code of chassis!!!

SHIPPING: Shipping international cargo sea service available to any country. Delivery time depend on final port of destination 25-35 days.
